Testomat® 808
Product number: 100650
€2,702.40*
Please log in to receive your conditions.
Available, delivery time: 1-2 days
Product number:
100650
GTIN:
4260682383815
Measurement parameters:
Total hardness
Measuring range:
Limit value total hardness 0.02 - 5 ° dH (0.4 - 89 ppm)
Application:
Applications of continuous residual hardness monitoring are for example: | Reverse osmosis plants | Boiler feed water supply | Soft water for commercial purposes | Pure water production plants
Our comment:
From now on, the Testomat® 808 gets delivered without integrated power switch for fulfilling the safety standard DIN EN 61010-1 for electrical equipment for measurement, control, and laboratory use. We recommend you the external power switch, order no 850925.
Would you like to register the warranty for this product?
Register warranty here
A warranty extension is possible after taking out an indicator subscription.
Register warranty here
A warranty extension is possible after taking out an indicator subscription.
Order the appropriate original indicator for your TESTOMAT® device:
Determine the appropriate indicator here: Indicator consumption calculator
| Testomat® 808 indicator 300 | Order · Subscription |
| Testomat® 808 indicator 300S 2 x 100 ml | Order · Subscription |
| Testomat® 808 indicator 301 2 x 100 ml | Order · Subscription |
| Testomat® 808 indicator 302 2 x 100 ml | Order · Subscription |
| Testomat® 808 indicator 303 2 x 100 ml | Order · Subscription |
| Testomat® 808 indicator 305 2 x 100 ml | Order · Subscription |
| Testomat® 808 indicator 310 2 x 100 ml | Order · Subscription |
| Testomat® 808 indicator 320 2 x 100 ml | Order · Subscription |
| Testomat® 808 Indicator 330 2 x 100 ml | Order · Subscription |
| Testomat® 808 indicator 350 2 x 100 ml | Order · Subscription |
| Testomat® 808 indicator 300 500 ml | Order · Subscription |
| Testomat® 808 indicator 300S 500 ml | Order · Subscription |
| Testomat® 808 indicator 301 500 ml | Order · Subscription |
| Testomat® 808 indicator 302 500 ml | Order · Subscription |
| Testomat® 808 indicator 303 | Order · Subscription |
| Testomat® 808 indicator 305 500 ml | Order · Subscription |
| Testomat® 808 indicator 310 | Order · Subscription |
| Testomat® 808 indicator 320 500 ml | Order · Subscription |
| Testomat® 808 indicator 330 | Order · Subscription |
| Testomat® 808 indicator 350 500 ml | Order · Subscription |
Offer as PDF
Login for addressed offer The entered number of pieces will be taken into account when creating the offer.
Login for addressed offer The entered number of pieces will be taken into account when creating the offer.
Product information "Testomat® 808"
The Testomat® 808 is a compact analyzer for the online measurement of water hardness according to the principle of " limit value monitoring by color change ". The Testomat® style="letter-spacing: 0px;"> 808 is a combination of the latest technologies based upon decades of international Testomat® experience.
Applications of continuous residual hardness monitoring are for example:
- Reverse osmosis plants
- Boiler feed water supply
- Soft water for commercial puposes
- Pure water systems
Performance profile:
- Limit value indication (not exceeded or exceeded: green / red LED)
- Modern indicator pump system
- Automatic measuring process with low water consumption
- Direct error and indicator quantity indication
- Internal and external flushing of the measuring chamber by manual control
- Control of an external rinsing valve
- Three potential-free relays for:
- External rinsing valve control
- Limit value evaluation
- External control and / or alarm processing
- Safety check for 72 hours operation without supervision
- Indicator quantities: 100 and 500 ml bottles
- 4 - 20 mA interface for defined status and error messages
- RS 232 interface for firmware updates
Dimensions
| Height | 31,4 cm |
|---|---|
| Length | 13,8 cm |
| Width | 36,4 cm |
Weight
| Weight | 5,6 kg |
|---|
Other attributes
| Country of origin | EU |
|---|---|
| Customs tariff number | 90278990 |
Technical specifications
| Power consumption: | max. 16 VA |
| Protection class: | I |
| Protection: | IP 44 |
| Ambient temperature: | 15–40 °C |
| Water temperature: | 10–40 °C |
| Dimensions (W x H x D): | 364 x 314 x 138 mm |
| Operating pressure: | 1 – 4 bar oder 0,3 – 1 bar* |
| Weight: | approx. 4,5 kg |
| Measuring range: | 0,4 - 90 ppm
|
We recommend our indicators, as well as the following accessories
Testomat® 808 indicator 300 500 ml
Product number:
141001
500 ml bottle original Testomat® 808/BOB 300 indicator for measuring residual hardness.
Limit value:
0,02°dH residual hardness
0.0356 °fH
0.356 ppm CaCO3
0.00356 °mmol/l
€101.00*
Testomat® 808 indicator 301 500 ml
Product number:
141003
500 ml bottle original Testomat® 808/BOB indicator 301 for measuring residual hardness.
Limit value:
0,1°dH residual hardness
0.178 °fH
1.78 ppm CaCO3
0.0178 °mmol/l
€101.00*
Testomat® 808 indicator 305 500 ml
Product number:
141006
500 ml bottle original Testomat® 808/BOB indicator 305 for measuring residual hardness.
Limit value:
0,5°dH residual hardness
0.89 °fH
8.9 ppm CaCO3
0.089 °mmol/l
€101.00*
Testomat® 808 indicator 310
Product number:
141007
500 ml bottle original Testomat® 808/BOB indicator 310 for measuring residual hardness.
Limit value:
1°dH residual hardness
1.78 °fH
17.8 ppm CaCO3
0.178 °mmol/l
€101.00*
Testomat® 808 indicator 330
Product number:
141009
500 ml bottle original Testomat® 808/BOB indicator 330 for measuring residual hardness.
Limit value:
3°dH residual hardness
5.34 °fH
53.4 ppm CaCO3
0.534 °mmol/l
€101.00*
